FYBER 16CH 12V Insta SMPS (Metal) | FW-116
Roll over image to zoom in
₹969.00₹1,260.00 inc.GST (-23%)
FW-116 is a FYBER 16CH 12V Insta SMPS (Metal) with 12VDC, 168W rated power and built-in overload, surge, short-circuit and thermal protection.
Please confirm the current price and stock on WhatsApp before completing your purchase.
Confirm Price / Stock on WhatsApp
Compare with similar SMPS / Power Supply products
MORE WAYS TO SAVE
More live CCTV offers
Compare these limited-price cameras before completing your order.
CCTV CAMERA
₹2,276.00₹2,208.00inc. GST
CP Plus ezyKam+ 2MP Wi-Fi PT Camera | Two-Way…
1 offer unit availableView offer →
CCTV CAMERA
₹2,850.00₹2,708.00inc. GST
Hikvision DS-2CE16U1T-ITPF 8MP 4K Ultra Low Light Bullet Camera…
1 offer unit availableView offer →
Product details
FYBER POWER & NETWORKING
FW-116 — 16CH 12V Insta SMPS (Metal)
Stable, protected power engineered for multi-camera CCTV installations.
Product overview
The FW-116 is a FYBER 16CH 12V Insta SMPS (Metal). It is designed to deliver a consistent 12VDC output with a rated power of 168W. The compact power design and built-in electrical protection make it suitable for dependable day-to-day surveillance and electronics deployments.
Regulated output
12VDC supports compatible equipment with stable power delivery.
Multi-layer protection
Overload, over-voltage, over-current, short-circuit and thermal safeguards help protect the power supply and connected load.
Installation ready
Designed for 150~265VAC input. Confirm connector, current demand and device voltage before installation.
Technical specifications
| Model | FW-116 |
|---|---|
| AC Input Voltage | 150~265VAC |
| DC Output Voltage | 12VDC |
| Rated Power | 168W |
| Ripple & Noise (max.) | 180mV(max) |
| Voltage Adj. Range | NA |
| Device | Primary-Side Regulation |
| Device (Frequency) | 132KHz |
| VDS Voltage | 616V(max) |
| Line Regulations | ±1% |
| Load Regulations | +5% |
| SCP | Output short-circuit protection |
| OPP, OCP | Over Current Protection |
| OVP | Over Voltage Protection |
| Line UV | Line brown-in/out protection |
| OV Line | Line overvoltage shutdown extends line surge withstand |
| OTP | Accurate thermal shutdown, hysteretic or latching |
| Efficiency (Typ.) | 83% |
| Frequency Range | 50~60Hz |
| Storage Temperature | 0~50°C |
Selection and installation guidance
Match the connected device voltage exactly and keep its maximum current or wattage within the power supply rating. Verify DC plug size and polarity before connecting. Install in a ventilated, dry location, avoid tightly coiling the output lead and do not use damaged connectors. For CCTV projects, allow practical headroom for night-time IR load and voltage drop.
Frequently asked questions
What output does FW-116 provide?
The official specification lists 12VDC and a rated power of 168W.
Can it power any CCTV camera or electronic device?
No. The device voltage, current requirement, connector size and polarity must all match. Confirm compatibility before ordering.
What protection is built in?
The FYBER specification includes protection against short circuit, overload or over-current, excess voltage and overheating. Protection features reduce risk but do not replace correct sizing and installation.
Is it suitable for continuous operation?
It is intended for reliable power delivery within its stated electrical and environmental limits. Keep ventilation clear and avoid overloading.
Technical reference: FYBER official FW-116 product data. Product appearance and specifications may be revised by the manufacturer; verify critical project requirements before purchase.
Additional information
| Brand | FYBER |
|---|---|
| Model Number | FW-116 |
| Output Voltage | 12VDC |
| Rated Power | 168W |
