Name: CP Plus CP-DPS-PD16-V2-12D 16CH Power Supply | 96W
SKU: CP-DPS-PD16-V2-12D
Price: 1145.00 INR
Availability: InStock

CP Plus 16CH Power Supply V2 — Per-Channel LEDs

⚡ 12V 8A / 96W: Sixteen distributed outputs from one unit.

💡 LED Indicator On All 16 Channels: Whole-site power status at a glance.

🎚️ Cable Compensation + 11.4–12.6V Adjust: Long runs covered.

🔋 86% Efficiency: Low 120mV ripple — clean analog video.

🛡️ Current-Limiting + EMI Filter: Overload auto-shutdown & recovery.

🏠 Slim Wall-Mount Design: 16-way distribution without a bulky cabinet.

Product details

⚡ CP PLUS 16CH POWER SUPPLY V2

16 LED Channels • 96W • Cable Compensation • Slim Body

Sixteen Cameras, One Control Panel

The CP Plus CP-DPS-PD16-V2-12D turns a 16-camera power plan into one tidy box: 16 distributed outputs, each with its own LED indicator, fed by a modern 86%-efficient SMPS delivering 12V at 8A (96W). The LED row reads like a control panel — every camera’s power status visible in one glance from the rack.

The cable compensation switch plus 11.4–12.6V adjustment keeps far cameras at full voltage, while the constant current-limiting circuit, EMI filter and auto-recovering overload protection (110–200% threshold) contain any single-channel fault without dropping the site. At just 39mm deep it wall-mounts flat where a metal cabinet wouldn’t fit.

💡 16 LEDs = Site Health Bar

Scan the row weekly: all lit means all powered. Any dark LED points you to the exact channel — maintenance becomes a 10-second ritual.

📐 Right-Sized for HD Fleets

96W across 16 channels suits standard HD camera fleets; for heavy IR/dual-light loads the MD200P 20A metal unit is the muscle option.

📊 Full Technical Specifications — CP-DPS-PD16-V2-12D

Model	CP-DPS-PD16-V2-12D
Output	12V DC, 0–8A, 96W rated
Channels	16, with LED indicator per channel
Voltage Adjustment	11.4–12.6V + cable compensation switch
Input	200–240VAC, 47–63Hz, ~2A/220VAC
Efficiency / Ripple	86% typical; ripple ≤120mVp-p; line reg ±1%
Protection	Constant current limiting, EMI filter, overload (110–200%) auto-shutdown & auto-recovery
Body	Plastic housing, 186×130.5×39mm, free-air cooling
Operating Temp	-20°C to +45°C, 20–90% RH
Warranty	2 Years CP Plus India

❓ Frequently Asked Questions

Is 8A enough for 16 cameras?
For standard HD cameras (~0.4–0.5A each) yes. If your fleet is IR-heavy or dual-light, choose the MD200P 20A metal supply instead.

This or the MD200P for a 16-camera site?
This V2: per-channel LEDs, slim body, standard loads. MD200P: double the amps, metal chassis, adjustable to 13.2V. Load decides.

Does one faulty channel affect the rest?
No — current limiting contains the fault and the supply auto-recovers once it clears.

Any camera brand?
Yes — any 12V DC CCTV camera.

🤝 Why BuyCCTVs.com?

BuyCCTVs.com Invoice — genuine billing, warranty protected
Managed Customer Support — one point of contact
Dealer-Network Sourcing — fresh genuine stock
Direct-to-Customer Dispatch — typically within 24 hours
Compatibility Guidance — full site load calculated before order
Remote Usage Guidance — wiring layout help included

🛠️ Warranty & After-Sales Support

2-Year CP Plus India Warranty, subject to BuyCCTVs.com invoice and serial validation; we coordinate the complete RMA process.

⚠️ Important: Keep total load within ~80% of rated amps for longest life. Please confirm current price and stock on WhatsApp before purchase.
