CP Plus 16 Channel 5M-N Hybrid DVR | 24 IP Channel Support | Full-Channel AI Instastream | Gigabit LAN | 2 Year Warranty | CP-UVR-1601F1-IC
₹15,051.00₹19,567.00 inc.GST (-23%)
CP Plus 16 Channel 5M-N Hybrid DVR
- 📹 16 Analog Channels at 5M-N: Sharp 5MP-class recording on standard coax cameras.
- ➕ 16+8 IP Channels (up to 6MP): Add IP cameras any time — up to 24 IP channels total.
- 🤖 Full-Channel AI Instastream + SMD Plus: Smart compression and human/vehicle filtering on every channel.
- 🗄️ 1 SATA up to 16TB: Big single-disk capacity for long retention.
- 🎤 16-Channel Coaxial Audio + Two-Way Talk: Sound on every camera through existing cable.
- ⚡ Gigabit LAN: Fast, smooth remote viewing via gCMOB and KVMS Pro.
Frequently Bought Together
-
₹2,172.00
₹2,824.00inc.GST -
₹2,113.00
₹2,747.00inc.GST
Product details
⚙️ CP PLUS 16CH 5M-N DVR
Hybrid Power • AI on Every Channel • Gigabit Fast
The Smart Middle Path: Analog Today, IP Tomorrow
The CP Plus CP-UVR-1601F1-IC records 16 coax cameras at crisp 5M-N resolution while quietly holding a superpower: hybrid support for up to 24 IP cameras (6MP each). Your current analog investment keeps working; your future IP upgrade already has a home.
AI Instastream runs on every channel, shrinking storage needs while SMD Plus classifies motion as human or vehicle — fewer false alerts, faster searches. A single SATA bay accepts disks up to 16TB, 16-channel coaxial audio adds sound without extra wiring, and the gigabit port keeps mobile viewing responsive with several users connected. For medium businesses, schools and larger homes, this is the sensible recorder that doesn’t force an either/or choice.
📦 What’s Inside the Box
| CP Plus 16Ch DVR Unit | CP-UVR-1601F1-IC |
| Power Adapter | 12V DC / 2A (included) |
| USB Mouse | For local setup & control |
| Quick Start Guide | Installation & app setup manual |
| HDD Screws & SATA Cable | For hard disk installation |
🔀 True Hybrid Freedom
Disable analog channels to unlock more IP capacity — reconfigure the mix as your site evolves, without buying new hardware.
💾 Storage That Stretches
AI Instastream on all 16 channels can cut storage consumption dramatically versus H.264 — the same disk holds weeks more evidence.
🎤 Sound Without New Wires
16-channel audio over coax plus RCA two-way talk — hear what happened, not just see it, using the cabling already in your walls.
📱 Remote Access via gCMOB
Live view, playback and push alerts on iOS & Android, with KVMS Pro for multi-site business monitoring.
📊 Full Technical Specifications — CP-UVR-1601F1-IC
| Model | CP-UVR-1601F1-IC |
| Analog Channels | 16 (BNC), 5M-N@10fps / 4M-N/1080P@15fps |
| IP Camera Support | 16+8 channels, each up to 6MP |
| AI Features | Full-channel AI Instastream, SMD Plus |
| Compression | AI Instastream / Instastream / H.265 / H.264+ / H.264 |
| HDD Bays | 1× SATA (up to 16TB) |
| Audio | 16-ch coaxial + 1 RCA in, two-way talk (G.711A/U, PCM) |
| Video Output | 1× HDMI + 1× VGA simultaneous |
| Network | 1× Gigabit RJ45 (10/100/1000) |
| USB Ports | 2× USB 2.0 |
| Mobile App | gCMOB / iCMOB, KVMS Pro CMS |
| Power / Physical | 12V DC / 2A, <12W; -10°C to +45°C; 260×231×48mm, 0.93kg |
| Warranty | 2 Years CP Plus India |
❓ Frequently Asked Questions
How many cameras can this DVR support?
16 analog cameras at 5M-N, plus IP cameras in hybrid mode — up to 24 IP channels (6MP each) as you disable analog inputs.
Does it come with a hard disk?
No — the HDD is sold separately. It accepts one disk up to 16TB; a 4–8TB disk suits most 16-camera sites.
Will my existing coax cameras work?
Yes — all standard HD analog cameras work; 5MP analog cameras unlock the full recording quality.
Does it record audio?
Yes — 16-channel audio over coax (with audio-capable cameras) plus RCA input and two-way talk.
🤝 Why BuyCCTVs.com?
- BuyCCTVs.com Invoice — genuine billing that protects your warranty claim
- Managed Customer Support — one point of contact, purchase to service
- Dealer-Network Sourcing — fresh genuine stock, valid India serials
- Direct-to-Customer Dispatch — typically within 24 hours
- Compatibility Guidance — we plan your analog/IP channel mix before dispatch
- Remote Usage Guidance — app, recording & alert setup after delivery
🛠️ Warranty & After-Sales Support
The CP-UVR-1601F1-IC carries a 2-Year CP Plus India Manufacturer Warranty, subject to BuyCCTVs.com invoice and serial-number validation. BuyCCTVs.com coordinates the complete RMA process — no service-centre trips required.
⚠️ Important: Hard disk not included. Please confirm current price and stock on WhatsApp before completing your purchase.
Additional information
| Warranty | 2 Year |
|---|---|
| Channels | 16 |
| Device Type | DVR |
| Max Resolution | 5MP |
| Compression | H.265 |
