Name: Dahua DHI-NVR5464-EI 64CH NVR
SKU: DHI-NVR5464-EI
Price: 50610.00 INR
Availability: InStock

Dahua NVR5464-EI 64-Channel WizSense EI Series Network Video Recorder

64 IP camera channels: Central recording for enterprise surveillance projects.

Up to 32MP camera input: Supports compatible IP streams within the recorder’s bandwidth and decoding limits.

384/384/384 Mbps incoming/recording/outgoing network bandwidth: Plan total camera bitrates before commissioning.

4 SATA bays up to 20TB each: Use surveillance-grade HDDs sized for the required retention period.

AcuPick, face, SMD and perimeter AI: Accelerates target search and filters security events at enterprise scale.

Smart H.265+ and remote access: Efficient recording with authorised mobile and browser viewing.

Product details

DAHUA WIZSENSE EI NETWORK RECORDING

NVR5464-EI 64-Channel NVR

32MP | 4 SATA bays up to 20TB each | 32-channel AcuPick | Smart H.265+

Model-specific recording for a dependable IP CCTV system

The Dahua DHI-NVR5464-EI is a 64-channel 1.5U WizSense network recorder with four HDD bays and 384 Mbps symmetric video bandwidth. It accepts compatible cameras up to 32MP and decodes up to thirty-two 1080p streams at 30 fps.

Recorder-side resources include two-channel face detection/recognition, eight-channel SMD, four-channel perimeter protection, eight-channel video metadata and up to thirty-two-channel AcuPick. N+M clustering and iSCSI are specified, but RAID is not claimed for this exact four-bay model.

Key benefits for installers and security teams

64-channel capacity: Sixty-four channels and high bandwidth support large multi-building or high-density installations.

4 SATA bays up to 20TB each: Four bays provide substantial local retention while iSCSI can support planned external storage architecture.

AcuPick, face, SMD and perimeter AI: AcuPick combines recorder and compatible camera intelligence to find relevant human or vehicle targets faster.

Technical specifications – NVR5464-EI

Model / type	DHI-NVR5464-EI; 64-channel WizSense EI Series NVR
IP camera inputs	64 channels; no built-in PoE on this model
Supported camera resolution	Up to 32MP, subject to stream and decoding limits
Network bandwidth	384/384/384 Mbps incoming/recording/outgoing
Decoding capability	Up to 32 × 1080p at 30 fps; resolution/layout combinations depend on mode
Recorder-side AI	2-ch face detection/recognition, 8-ch SMD, 4-ch perimeter, 8-ch metadata and up to 32-ch AcuPick
Camera-side analytics	Compatible camera analytics can include face, metadata, perimeter, SMD, people counting, heat map and ANPR
Video compression	Smart H.265+, H.265, Smart H.264+ and H.264; camera/stream dependent
Display outputs	HDMI outputs including 4K plus VGA; verify independent display layout requirements
Storage	4 SATA bays, up to 20TB per HDD; N+M cluster and iSCSI support. RAID is not stated for this exact model
Network / interoperability	Dual Gigabit Ethernet-class networking, N+M clustering, iSCSI and remote access; ONVIF/RTSP or supported Dahua protocols depending on camera
HDD / PoE included	No HDD and no PoE switch are included unless an offer explicitly states otherwise
Warranty	2 Years Dahua India, subject to invoice and serial validation

Where this NVR fits

Intended for factories, campuses, hospitals, malls, logistics centres and large residential projects needing 64 channels, four local HDDs and advanced target investigation.

Recording days are not fixed. They depend on camera count, resolution, codec, frame rate, bitrate, recording schedule, scene activity and installed surveillance-HDD capacity.

Compatibility, bandwidth and AI planning

Before ordering, total the main-stream and sub-stream bitrates, required live-view layouts, simultaneous playback, display resolution, analytics and retention. Maximum camera resolution does not mean every channel can be decoded at that resolution simultaneously.

ANPR is listed as a compatible camera-side analytic, not a recorder-side ANPR engine. Do not describe the four-bay NVR5464-EI as RAID-capable unless separate official regional documentation for the supplied hardware confirms it.

Frequently asked questions

Does NVR5464-EI include a hard disk?

No. Select compatible surveillance-grade HDD capacity based on the desired recording duration.

Does it have built-in PoE ports?

No. This exact non-P model requires a suitable external PoE switch or separately powered IP cameras.

Will every ONVIF camera feature work?

Basic video commonly works, but audio, events, configuration and AI metadata vary by camera model, profile and firmware.

Can all AI functions run together?

Not always. Recorder resources, camera-side analytics and firmware determine simultaneous AI capacity.

Why buy from BuyCCTVs.com?

Exact SKU and non-P/PoE version checking
Bandwidth, decoding, AI and storage guidance
Genuine invoice and India-wide support

Professional installation note

Use protected power, adequate rack ventilation, surveillance HDDs and a secured network. Change default credentials and use firmware approved for the exact hardware version.

Additional information

Device Type	IP NVR
Channels	64-Channel
Max Resolution	32MP
AI	2-ch Face + 8-ch SMD + 4-ch Perimeter + AcuPick
Compression	Smart H.265+
Storage	4 SATA up to 20TB each
Output	4K HDMI + VGA
PoE	No (needs external PoE switch)
Warranty	2 Year
