The CP Plus CP-UVR-1601E1-IC2 covers big sites on a working budget: 16 analog channels at 1080N, 8-channel SMD Plus human/vehicle filtering to keep alerts honest, and H.265+/Instastream dual-stream compression that makes a single 16TB disk last impressively long.
Hybrid support scales to 18 IP channels at 64Mbps for gradual modernization, 16-channel coaxial audio adds sound over existing cable, and ONVIF 21.06 keeps future camera choices open. The dependable centre of a large coax system that doesn’t need frills — just coverage that works.
💰 Cost per Channel Champion
Spread across 16 channels, this DVR delivers the lowest smart-recording cost in our range — godowns, societies and schools take note.
💾 H.265+ Retention Math
H.265+ dual-stream can cut storage needs by half or more versus H.264 — the same disk holds weeks longer, or you buy a smaller disk.
📊 Full Technical Specifications — CP-UVR-1601E1-IC2
Model
CP-UVR-1601E1-IC2
Analog Inputs
16 BNC — 1080N/720p main stream (960H/D1/CIF supported)
IP Support
Up to 18 IPC channels (2 default + conversion), 64 Mbps
AI
SMD Plus 8-ch — human/vehicle secondary filtering
Compression
H.265+ / H.264+ / H.264, Instastream dual-stream
Audio
1 RCA + 16-ch coaxial (G.711A/U, PCM)
Storage
1× SATA, up to 16TB
Video Output
1× HDMI + 1× VGA (1920×1080)
Network
RJ45 — HTTPS, RTSP, IPv4; ONVIF 21.06
Power
12V DC 1.5A, <10W without HDD
Warranty
2 Years CP Plus India
❓ Frequently Asked Questions
IC2 or E1V-I — which 16ch model? The E1V-I adds full-16-channel IMD+ and two-way talk; this IC2 offers SMD Plus and H.265+ at the same price point with 16TB support. Talk features matter → E1V-I; pure recording value → IC2.
Does it come with a hard disk? No — sold separately (up to 16TB). We size it for your retention target.
Will my old cameras work? Yes — standard analog formats record at their native resolution up to 1080N.
Can I add IP cameras later? Yes — up to 18 IP channels by converting analog inputs, 64Mbps total.
🤝 Why BuyCCTVs.com?
BuyCCTVs.com Invoice — genuine billing that protects your warranty claim
Managed Customer Support — one point of contact, purchase to service
Dealer-Network Sourcing — fresh genuine stock, valid India serials
Direct-to-Customer Dispatch — typically within 24 hours
Compatibility Guidance — cameras & HDD confirmed before order
Remote Usage Guidance — gCMOB & recording setup after delivery
🛠️ Warranty & After-Sales Support
The CP-UVR-1601E1-IC2 carries a 2-Year CP Plus India Manufacturer Warranty, subject to BuyCCTVs.com invoice and serial-number validation. BuyCCTVs.com coordinates the complete RMA process.
⚠️ Important: Hard disk not included. Please confirm current price and stock on WhatsApp before completing your purchase.
Save -23% on CP Plus 16 Channel 1080N DVR | H.265+ | SMD Plus AI | 18 IP Support | 16TB SATA | 2 Year Warranty | CP-UVR-1601E1-IC2! Only ~₹10,421.00~ ₹8,016.00 — ask us before it's gone.
