Project Roll • Pure Copper • Standard Grade • Best ₹/Metre
The Whole-Site Roll
Wiring an 8 or 16-camera site from 70m rolls means leftover stubs, extra joints and repeated purchases. The CP Plus CP-ECC-180RS solves the economics: 180 continuous metres of Standard-grade 3+1 cable — the best rupees-per-metre in the range — cut to exact run lengths with no joints and minimal waste.
Construction is the proven RS Standard recipe: solid annealed pure copper video core (0.52mm) under a 48-strand AL alloy braid, stranded copper power cores and an audio line in one jacket. Every camera on the site gets the same clean, shielded HD signal — pair with a cable-compensation power supply for the longest runs.
💰 Project-Roll Economics
One 180m roll costs less per metre than three 70m rolls — and cut-to-length wiring means every camera run is joint-free.
🛡️ Same Grade, Every Run
48-strand shielding and pure copper throughout — no mixing cable qualities across cameras, no "why is camera 7 grainy" mysteries.
📊 Full Technical Specifications — CP-ECC-180RS
Model
CP-ECC-180RS (Standard Series)
Construction
3+1 — video, power & audio communication
Length
180 metres
Video Core
Solid annealed pure copper, 0.52±0.02mm
Braiding
AL alloy, 48 strands
Power Cores
Stranded copper, PVC insulated
Application
HD analog CCTV — video, power & audio
❓ Frequently Asked Questions
How many cameras will 180m wire? At typical 15–20m runs, roughly 8–12 cameras — measure your longest runs and plan with 10% slack.
Indoor or outdoor? This RS grade suits indoor and protected routes; for direct sun and rain exposure choose the RSO outdoor version.
Is it really pure copper? Yes — solid annealed bare copper video core, not copper-clad steel. That’s what keeps HD video sharp at distance.
Smaller job? The same Standard grade comes in 70m (CP-ECC-70RS) and 90m (CP-ECC-90RS) rolls.
Save -23% on CP Plus 3+1 CCTV Cable 180M | Pure Copper | 48-Strand Braid | Standard Series | CP-ECC-180RS! Only ~₹4,263.00~ ₹3,279.00 — ask us before it's gone.
