Hikvision DS-1LN6U-G 305M Cat6 Copper Cable

9,200.009,800.00 inc.GST (-6%)

In stock

305 m CAT6 UTP Network Cable (Solid Copper, 0.55 mm, Gray)

  • Full diameter 305 m CAT6 network cable
  • Core diameter: 0.55mm
  • Excellent transmission performance using solid copper
  • Quality verified by Fluke test
  • Guaranteed long PoE transmission distance
  • Great PVC flame resistance.

The Hikvision DS-1LN6U-G 305M Cat6 Copper Cable is a high-quality network cable designed for reliable and fast data transmission. It is perfect for connecting Camera & devices in a home or office network setup.

Accessories

  • Category Cat.6
  • Steath Printing HIKVISION 4PR 23AWG 75℃ U/UTP CAT6 VERIFIED TO ANSI/TIA-568-C.2 PVC ****m mm/dd/yyyy Tracing Code-HS
  • Reference Standard ISO/IEC11801,ANSI/TIA-568-C.2,RoHS 2.0
  • Fire Resistance No
  • Conductor Solid-Bare Copper (99.95%);0.55±0.005 mm,23 AWG
  • Insulation HDPE;0.98±0.05 mm
  • Rip-Cord Yes
  • Separator Yes

Sheath Physical Properties

  • Before Aging Tensile strength ≥ 13.5 Mpa;Elongation ≥ 150%
  • Aging Period 100 ℃ × 24h × 10d
  • After Aging Tensile strength ≥ 12.5Mpa;Elongation ≥ 125%
  • Cold Bend-20 ± 2℃ × 4h,8 × cable O.D,no visible cracks

Electrical Characteristics(20℃)

  • 1.0-250.0 MHz Impedance 100 ± 15Ω @ ≤ 100MHz;100 ± 25Ω @ 100-250MHz
  • 1.0-250.0 Mhz Delay Skew ≤ 45 ns/100 m
  • DC Resistance ≤ 9.38 Ω/100 m
  • DC Conductor Resistance Unbalance ≤ 5.0 %
  • Package Dimension 400 mm (W) × 400 mm (H) × 240 mm (D)(15.75″ × 15.75″ × 9.45″)
  • Weight 12.3 ± 0.5kg
  • Cable Length (305 ±1.5) m
  • Ambient Temperature -20 ℃ to 75 ℃ (-4℉ to 167℉)
  • Operating Voltage 60 V

Sheath

  • Thickness 0.5±0.10 mm
  • Material PVC
  • Color Grey
  • Diameter 6.00±0.30 mm
